Camera

• Image Sensor 2 MP CMOS image sensor

• Signal System PAL/NTSC

• Frame Rate “PAL: 1080p@25fps
  NTSC: 1080p@30fps

• Resolution 1920 (H) × 1080 (V)

• Min. illumination 0.02 Lux @ (F1.2,AGC ON), 0 Lux with IR

• Shutter Time “PAL: 1/25 s to 1/50, 000 s
  NTSC: 1/30 s to 1/50, 000 s

• Lens 2.8 mm, 3.6 mm fixed lens

• Horizontal Field of View 103° (2.8 mm), 82.2° (3.6 mm)

• Lens Mount M12

• Day & Night IR cut filter

• Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°

• Synchronization Internal synchronization

• WDR (Wide Dynamic Range) DWDR
