Camera

• Image Sensor- 1 MP CMOS image sensor
• Signal System- PAL/NTSC
• Effective Pixels- 1280 (H) × 720 (V)
• Min. Illumination- 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter Time- 1/25 (1/30) s to 1/50,000 s
• Lens- 2.8 mm, 3.6 mm, 6 mm
• Horizontal Field of View- 92° (2.8 mm), 70.9° (3.6 mm), 56.7° (6 mm)
• Lens Mount- M12
• Day & Night- IR cut filter
• Angle Adjustment- Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
• Synchronization- Internal synchronization
• Video Frame Rate- PAL:720p@25fps
  NTSC: 720p@30fps
